抽屜式烘箱是指有1- 6層獨立加熱區的烘箱,每層可獨立控溫、單獨使用或聯動使用。
Drawer-type Oven refers to the oven with 1-6 layers of independent heating area, each layer can be independently controlled, used alone or linked together.
抽屜式烘箱是指有1- 6層獨立加熱區的烘箱,每層可獨立控溫、單獨使用或聯動使用。
Drawer-type Oven refers to the oven with 1-6 layers of independent heating area, each layer can be independently controlled, used alone or linked together.
選配：1.桁架上料機械手；2.壓機上下料機器人
Optional: 1. Truss feeding manipulator; 2. Robot of press machine
*可根據客戶的需求定制
*Able to be customized
*參數及圖片可能變化，具體以技術協議為準
*Parameters and photos may vary. The technical agreement prevails.
序號 S/N | 型號Model | 加熱區數量Number of heating zones | 最高設定溫度℃ Max. Temperature ℃ | 最大加熱材料（L*W） Max. Heated Material (L*W) | 爐盤伸縮速度 mm/s Expansion speed of hearth mm/s | 爐盤伸縮行程mm Expansion stroke of hearth mm | 溫度均勻度 Temperature uniformity | 溫度波動度 Temperature fluctuation |
1 | HW-HAC-MO11720CB | 1 | 300 | 1700*2000 | 1-800 | 1800 | ±2% | ±1℃ |
2 | HW-HAC-MO21720CB | 2 | 300 | 1-800 | 1800 | ±2% | ±1℃ | |
3 | HW-HAC-MO51720CB | 5 | 300 | 1-800 | 1800 | ±2% | ±1℃ | |
4 | HW-HAC-MO11928CB | 1 | 300 | 1900*2800 | 1-800 | 2000 | ±2% | ±1℃ |
5 | HW-HAC-MO21928CB | 2 | 300 | 1-800 | 2000 | ±2% | ±1℃ | |
6 | HW-HAC-MO51928CB | 5 | 300 | 1-800 | 2000 | ±2% | ±1℃ | |
7 | HW-HAC-MO12130CB | 1 | 300 | 2100*3000 | 1-800 | 2200 | ±2% | ±1℃ |
8 | HW-HAC-MO22130CB | 2 | 300 | 1-800 | 2200 | ±2% | ±1℃ | |
9 | HW-HAC-MO52130CB | 5 | 300 | 1-800 | 2200 | ±2% | ±1℃ |
